The MX series microscopic video measuring machine combines microscopic imaging with traditional image measurement, enabling large-scale measurement of minute features. Equipped with a motorized zoom module, it can automatically switch between different magnifications to probe various precise microscopic two-dimensional features. It offers rich dimensional measurement functions, capable of measuring various two-dimensional points, lines, circles, etc., and evaluating geometric tolerances.
The MX series video measuring machine can be used in precision machinery, optical communication devices, precision molds, magnetic materials, precision stamping, mobile phone precision components, medical devices, watches, cutting tools, metrology and testing, and other fields.
Microscopic fusion, global measurement
1. Microscopic size detection, specifically designed to discern minute structures that are difficult to distinguish with conventional imaging instruments, delivers clear imaging and precise measurements.
2. Breaking through field-of-view limitations, it integrates microscopic imaging with large-scale image measurement, balancing high resolution and a wide measurement range.
3. An ultra-precise microscopic optical system provides sharp imaging of micrometer-level details, automatic sub-pixel extraction, and highly consistent measurement results.
4. A high-precision positioning system maintains micrometer-level motion accuracy and positioning stability even under a microscopic field of view.
5. A microscopic-level vibration-resistant design isolates low-frequency vibrations, achieving sub-micrometer-level accuracy and stable, reliable high-magnification imaging.
Strobe lighting source, high-speed fly-shooting
1. Equipped with a strobe lighting source, support strobe and normal lighting modes.
2. Support fly-shooting measurement mode, measurement efficiency is increased by 5~10 times.
3. Support the stitching measurement function of the flash measuring machines.
High magnification, ultra-clear, high precision
1. The zoom lens can be equipped with 5X, 10X, and 20X objectives to achieve measurements of even smaller dimensions.
2. Ultra-precision microscopic optical systems enable clear imaging of minute dimensional features.
3. High-precision positioning and automatic sub-pixel extraction ensure consistent and stable measurement results every time.
Automatic and fast batch measurement
1. The program matches the workpiece coordinate system and automatically executes the measurement
process.
2. Support importing drawings in DXF, DWG, GER, GBR, BMP, and PDF.
3. Can execute quick and accurate batch measurements in CNC fixed coordinate system mode.
Abundant accessories, supporting various composite measurements
1. Supports an optical probe for high-precision height and flatness measurements.
2. Supports input from external devices such as calipers and micrometers, with unified data management.
3. Vision X measurement software supports 2.5D measurement tools.
Easy operation, hassle-free
1. Equipped with a large FOV navigation camera for fast workpiece positioning.
2. Mechanical lens anti-collision function
3. User-friendly operation interface; anyone can easily set and measure.
The software is feature-rich and includes automatic reports.
1. It provides up to 80 feature extraction, auxiliary construction, intelligent annotation, geometric tolerance, and special application analysis tools.
Automatically generates SPC analysis reports, supports Q-DAS transmission, and supports remote data integration.
| Model | MX342 | |||
| Travel Range | X (mm) | 300 | ||
| Y (mm) | 400 | |||
| Z (mm) | 200 | |||
| Structure Type | Bridge | |||
| Base Material | Granite | |||
| Monitor (Optional) | 24” LCD (1920×1080) | |||
| Resolution of Glass Scale | 0.1μm | |||
| Motion Guide Rail | Precision linear guide | |||
| Microscopic Zoom Module | Lens | 3:1 motorized lens | ||
| Image Sensor | High-definition industrial color camera | |||
| Standard | 10X | Magnification*1 | Optical zoom: 7.5X~22.5X, Image zoom: 182~545 | |
| F.O.V | Max: 1.1x0.8mm; Min: 0.35x0.275mm | |||
| Optional | 5X | Magnification*1 | Optical zoom: 3.75X~11.25X, Image zoom: 91~272 | |
| F.O.V | Max: 2.2x1.6mm; Min: 0.7x0.55mm | |||
| 20X | Magnification*1 | Optical zoom: 15X~45X, Image zoom: 364~1090 | ||
| F.O.V | Max: 0.55x0.4mm; Min: 0.175x0.137mm | |||
| Light | Back Light | Telecentric transmission illumination (White) | ||
| Ring Light | 4 rings and 8 segments surface light (White) | |||
| Coaxial Light | LED | |||
| Measurement Accuracy*2 | Single F.O.V | 5X | ±0.8μm | |
| 10X | ±0.6μm | |||
| 20X | ±0.3μm | |||
| X/Y | (0.8+L/250)μm | |||
| X⊥Y | (1.3+L/250)μm | |||
| Z*3 | (1.5+L/200)μm | |||
| Max Speed | XY | 100 mm/s | ||
| Z | 100 mm/s | |||
| Fly-Shooting Mode | Support | |||
| Height Meas.*4 | Optional: (1) Touch Probe; (2) Optical Probe; | |||
| Size (mm) | 860×1340×1685 | |||
| Weight (kg) | 900 | |||
| Loading Capacity (kg) | 25 | |||
| Power | 2000W | |||
| Motion Control | Servo control system | |||
| Software | VisionX | |||
| Input | 200-240VAC，50/60Hz | |||
| Working Environment | Temp. 20°C±2°C, Humidity 20~80%, Vibration <0.002g, Less than 15Hz | |||
Note:
*1 Image magnification is an approximate value; the specific value depends on the size and resolution of the display.
*2 In the focusing position, when the ambient temperature is 20°C±1°C, the weight on the stage is less than 5 kg, and L is the stage movement distance (mm).
*3 The test was conducted using a probe and a CHOTEST standard gauge at an ambient temperature of 20°C ± 1°C.
*4 Two height measurement sensor heads are optional.
